Ultrawave II PRODUCT SPECIFICATIONS

Wavelengths: 755nm Alexandrite, 1064nm Nd Yag (Long and Short), IPL (Optional Add-On), 1320nm Nd Yag (Optional Add-On),

755nm:

Pulse Width: 2-100 ms

Repetition Rate: up to 2 Hz

Spot Size: up to 16 mm

Max Fluence: up to 25 J/cm2 @ 14 mm

1064 Long Pulse:

Pulse Width: 3-300 ms

Repetition Rate: up to 2 Hz

Spot Size: up to 12 mm

Max Fluence: up to 480 J/cm2 @ 4 mm

1064 Short Pulse:

Pulse Width: 0.3-0.8 ms

Repetition Rate: up to 7 Hz

Spot Size: up to 8 mm

Max Fluence: up to 25 J/cm2 @ 5 mm

1320nm (Optional Add On):

Pulse Width: 5-10 ms

Repetition Rate: up to 5 Hz

Spot Size: up to 8 mm

Fluence: up to 35@6mm J/cm2

IPL (Optional Add On):

IPL Filters:650, 625, 590, 570, 550, 400 Filters

Pulse Width: 5-240 ms

Spot Size: 48×13 mm2 – 25x13mm2

Max Fluence: up to 30 J/cm2

Repetition Rate: 0,5

Skin Cooler: Integrated (Optional)

Electrical Requirements: 220-230 V AC; 16 A, 50-60 Hz

Dimensions and Weight: 900(W) x 480(L) x 930(H) mm3; 85-90 Kg

Ultrawave II MANUFACTURER NOTES

Indicated Uses:

• All skin type laser hair removal
• Benign vascular and pigmented lesions
• Skin Rejuvenation
• Acne scars
• Wrinkles

Long pulse Alexandrite 755 nm AND Short and Long Pulse Nd:YAG 1064 nm Indicated Uses:

• Hair removal treatments on all skin types.

Alexandrite (755 nm) Laser Indicated Uses:

• Coagulation and hemostatis of vascular lesions
• Removal and permanent reduction of unwanted hair in the Fitzpatrick skin types I-VI, including suntanned skin types
• Pigmented lesions
• Wrinkles

The Nd:YAG 1064 nm Short Pulse and Long Pulse Laser Indicated Uses:

• Coagulation and hemostasis of benign vascular lesions such as, but not limited to, port wine stains, hemangiomas, warts, telangiectasia, rosacea, venus lake, leg and spider veins and poikiloderma of Civattte and treatment of benign cutaneous lesions such as warts, scars, striae and psoriasis.
• Benign pigmented lesions such as, but not limited to, lentigos (age spots), solar lentigos (sun spots), cafe au lait macules, seborrheic keratoses, nevi, chloasma, verrucae, skin tags, keratoses, tattoos (significant reduction in the intensity of blue and/ or black tattoos), and plaques.
• Pigmented lesions to reduce lesion size, for patients with lesions that would potentially benefit from aggressive treatment, and for patients with lesions that have not responded to other laser treatments.
• Facial wrinkles and wrinkles such as, but not limited to, periocular and periorbital wrinkles.
• Removal of unwanted hair, for the stable long-term, or permanent hair reduction through selective targeting of melanin in hair follicles, and for the treatment of pseudofolliculitis barbae (PFB).
• Reduction of red pigmentation in hypertrophic and keloid scars where vascularity is an integral part of the scar.
• Use on all skin types (Fitzpatrick I-VI) including tanned skin and the removal and permanent reduction of unwanted hair in the Fitzpatrick I-VI, including suntanned skin types.

IPL Filters Indicated Uses:

650 Hair Removal

625 Hair Removal

590 Hair Removal

570 Facial Vascular and Benign Pigmented Lesions

550 Facial Vascular and Benign Pigmented Lesions

400 Inflammatory Acne Treatments

1320nm Indicated Uses:

• Periorbital and Perioral Wrinkles
• Fine Lines and Wrinkles

Cost of New Flash Lamp = $700-$900 plus the cost of installation

Cost of Service Technician Visit = about $700
