Sunetics Model G PRODUCT SPECIFICATIONS
Laser Type: AlGaInP
Number of Lasers: 107 separate laser diodes
Laser Classification: Class 1M (Safest Rating given by FDA for laser device)
Wavelength: 650 nm (+/-5nm), True Laser (NOT LED)
Output Power: 5mW each laser module; Total Output Power = 514 mW, MTBF 5,000 hours, Lasers 5VDC, <30mA per diode
Radiation: Visible Red Light, Continuous Wave, Uncollimated Beam, Utilizes Patented Laser Beam Dispersion Technology
Lamp Life: 5,000 hours
Laser Delivery: Direct from Source
Programmability: Timer – Increments from 10 to 30 minutes; Laser 100% duty cycle; Manual Override On/Off Switch
Display: Total treatment time, time remaining, total unit hours, user selectable front panel control
Laser Treatment Area Control: Laser panel designed for both scalp and facial treatment. (Some doctors also use this device for photofacial work)
Safety: Start / Stop / Pause programming switch. Unit sounds a warning beep with 2 minutes left of treatment
Power Consumption: 100-240VAC, 50-60Hz at 4.5A, UL / CE listed power system
Environmental: Operating -40 to 90 degrees Fahrenheit, 10-90% humidity, non-condensing
External Features: Caster Wheels, External Lock and Key
Certification: CE Certified, UL 6060-1 Certified, FDA & CDRH approved
Dimensions: Laser Base 18 x 18 inches, Top Laser 20.5 x 18 inches, with Arm 67.5 inches tall
Weight: 150 lbs
Sunetics Model G MANUFACTURER NOTES
The Sunetics Model “G” Clinical Laser system is the most powerful and effective Low Level Laser Therapy device currently available in the US and International market. Utilizing 107 (650nm 5mw) true laser modules and proprietary control software, its design is truly state-of-the-art for the professional marketplace.
Sunetics has designed this unit for long-term durability. The entire unit body is heavy gauge aluminum with a very substantial feel and presence. The open-hood design and laser pattern is designed to give a 100% coverage of the treatment area without need for noisy, failure-prone hooded designs. The laser head is easily adjusted by use of the counterbalanced arm assembly.
“Because of the patented laser dispersion technology that Sunetics utilizes the Clinical Laser has the ability to completely saturate the whole scalp evenly and offers enough power to effectively penetrate the hair, thus maximizing the results for the patient. To achieve the same results without using the Sunetics dispersion technology, one would have to use over 235 collimated laser beams. That gives you an idea of the dynamic of the dispersion technology.” says Dr. Charles Maricle.
Very little maintenance is needed for the laser. Simply wipe down the glass inside the laser head to keep gels and spray residue off the glass.
Sunetics has designed this unit for long-term durability. The entire unit body is heavy gauge aluminum with a very substantial feel and presence. The open panel hood design and laser pattern is designed to give a 100% coverage of the treatment area without need for noisy, failure-prone hooded designs. The laser head is easily adjusted by use of the hydraulic counterbalanced arm assembly. Therefore, the Sunetics Laser is built to last for years of treatments.
Lamp Life: 5,000 hours
