Rohrer Spectrum PRODUCT SPECIFICATIONS

810 Diode Handpiece Specifications

Spot Size:  12mm x 10 mm

Pulse Width:  3.3 – 200 ms

Pulse Rate:  0.5 – 10 Herz (pulses per second)

Energy Density:  2-120 J/cm2

IPL Handpiece Specifications

Indicated Uses for 4 Filters:

650 nm (HR) for Hair Removal

540 nm (SR) Filter for Skin Rejuvenation

510 nm (VR) Filter for Vascular & Pigmented Lesions, Melanin, Seborrheic Keratosis, & Photo Damaged Skin Lesions

450 nm (AR) Filter for Acne & Atrophic Acne Scars

Maximum Fluence: 35 J/cm2

Wavelength: 450 to 1200 nm

Spot Size: 35 x 15 mm

Repetition Rate: 1 Pulse every 3 seconds

Cooling: Self-Contained Closed Loop

Erbium Yag Handpiece (2940 nm) Specifications

Application: Laser skin resurfacing, skin ablation and coagulation, wrinkle and scar reduction

Energy: Up to 1000 mJ

Max Power: 2.4 W

Pulse Width: 300 us

Wavelength: 2940 nm

Beam Divergence: Collimated

Spot Size: 1.5 to 6 mm (with zoom lens)

1064 Long Pulse Nd Yag Handpiece Specifications

Wavelength: 1064 nm

Q-Switched Handpiece Specifications

Energy: Up to 1000 mJ

Maximum Fluence: 12 J/cm2

Wavelength: 1064 nm and 532 nm

Spot Size: 1.5 to 4 mm (with zoom lens)

Pulse Width: 10 to 15 ns

Repetition Rate: 1 to 6 Hz

Spectrum MANUFACTURER NOTES

WHY THE SPECTRUM?

The Spectrum is the ideal Laser/IPL system for sharing or for physicians with multiple locations. The system easily separates into two pieces and can be placed into the trunk or back of an SUV.

Features & Benefits:

• NO Consumables or Disposables

WHAT THE SPECTRUM INCLUDES

810-Diode | Hair Removal

The Spectrum is ideal for laser hair removal with a large spot size, a hertz rate capable of up to ten pulses per second, and built-in contact cooling.

Intense Pulsed Light

The intense pulsed light (IPL) has four filters that technicians can utilize for various non-abrasive procedures, including acne reduction, vascular and pigmented lesions removal, and hair reduction.

Q-Switched Yag/KTP | Tattoo Removal

The spectrum includes a laser tattoo removal device known as the Q-Switched Yag/KTP laser. The Q-switched Yag laser uses dual wavelengths (1064nm/532nm) to remove a vast range of tattoo pigments.

Long Pulsed Yag | Vascular Reduction

The Long-Pulsed Yag laser reduces vascular lesions, commonly known as spider veins, by using energy to heat, damage, and collapse targeted blood vessels. Technicians can also utilize the Long-Pulsed Yag to remove different types of vascular lesions, including cherry angioma.

Erbium Yag | Skin Resurfacing

Erbium is a skin resurfacing procedure for the face, neck, chest, and hands to eliminate surface pigmentation and minimize mild to moderate fine lines and wrinkles. The Erbium treatment requires minimal downtime but helps patients achieve dramatic results.
