ProNox CONSUMABLES

Does the ProNox Require Consumable? Yes

Patient Breathing Circuits (Disposable): These are single-use sets that include:

• A cushioned mask (small, medium, or large) or a mouthpiece.
• A standard nose clip.
• 5-foot long magenta tubing.
• A bacterial/viral filter.

Medical Gases:

• Medical-grade Nitrous Oxide (N2O).
• Medical-grade Oxygen (O2).

Filters: Staff/patient filters for additional hygiene.

Why They’re Needed:

Hygiene & Safety: Disposable circuits prevent cross-contamination and are crucial for infection control, with fresh tubing for each patient.

Patient Comfort: Available in different sizes to fit patients.

Gas Supply: The system mixes N2O and O2; cylinders must be replaced as they run low, triggering alarms.

Where to Find Them:

These items can be purchased directly from any authorized distributors.

ProNox PRODUCT SPECIFICATIONS

(Minimum) Peak Flow rate – 120 LPM

Inhalation Resistance –  0 to -6 cmH2O @ 60 LPM

Exhalation Resistance –  0 to 6 cmH2O @ 60 LPM

Input Pressure –  50 – 70 PSI (3.5-4.8 Bar)

Oxygen Concentration –  42.5 to 57.5%

Initiation Pressure – -2.5 cmH2O

Operating Temperature –  41°F to 104°F (5°C to 40°C)

Storage Temp – -40°F to 140°F (-40°C to 60°C)

Nitrous Oxide Input Connection – CGA1040 DISS

Oxygen Input Connection – CGA1240 DISS

Patient Connector – 15/22 mm

Patient Circuit – Single Use Patient Circuit c/w Scavenging port and filter

Patient Valve Dead Space –  8 ml

Weight – 53 oz. (1.5 Kg)

Dimensions – W x D x H : 8.9 x 6.6 x 3.9 (inches) 226 x 168 x 99 (mm)

Pro-Nox MANUFACTURER NOTES

What is Pro-NOX Anesthesia? The Pro-NOX System contains a blend of oxygen and nitrous oxide, a colorless, non-flammable gas. Nitrous oxide is usually more well known as “laughing gas.” For over a century, it has been used as a safe and effective method of pain relief during medical and dental procedures.

The PRO-NOX Nitrous Oxide Delivery System is a pneumatically driven gas mixer designed to deliver a 50% Oxygen and 50% Nitrous Oxide gas mixture to adult and pediatric patients for the relief of pain in a medical setting. The demand valve integrated into the main device housing minimizes risk of patient-to-patient cross-contamination. Minimal user controls and enhanced safety features make this the safest nitrous oxide mixer available.
