Rapid-Vanish RECERTIFICATION & CONSUMABLES

Recertification: Does Sharplight charge a recertification fee? Unknown

SharpLight Rapid‑Vanish

Consumables:
This system does not require consumables.

Rapid-Vanish PRODUCT SPECIFICATIONS

Wavelength Ranges:

HR 635 (DPC/IPL): Broad‑spectrum 600–950 nm (approx., varies by internal filtering)

LP 1064: 1064 nm (Long‑Pulse Nd:YAG Laser)

Energy:

Up to ~25–30 J/cm²

Pulse Duration:

10–100 ms adjustable (DPC/IPL)

Up to ~50 ms (LP 1064, varies by pulse mode)

Pulse Structure:
Single, Double, Triple (Dynamic Pulse Control)

Repetition Range:

Up to ~1–2 Hz (varies by DPC mode and fluence)

Spot Sizes:
• HR 635 – 6.4 cm² (primary hair‑removal spot)

• HR 635 – 3.4 cm² (secondary spot, depending on configuration)

• LP 1064 – ~6 mm–10 mm equivalent (varies by handpiece design; NOT a large IPL spot)

Dimensions:

• 102.7 cm (H) × 44 cm (W) × 46 cm (D)

• Weight: 53 kg

Technology:
Dynamic Pulse Control (DPC) — Broad‑Spectrum IPL Platform + Optional 1064 nm Long‑Pulse Nd:YAG Laser.

Handpiece System:
HR 635 – DPC/IPL & LP 1064 – Long‑Pulse Nd:YAG Vascular Handpiece

Treatment Capabilities:

• Permanent hair reduction (HR 635)
• Photofacial rejuvenation (HR 635)
• Pigment correction (HR 635)
• Vascular lesion treatment (LP 1064)
• Facial redness / rosacea (LP 1064 + HR 635)

Power Requirements:
110–240 VAC (auto‑switching), region dependent

Handpieces

HR635 – Hair Removal

Permanent hair reduction for the face and body. Effective on upper lip, chin, cheeks, jawline, neck, underarms, arms, legs, bikini area, and back. Also used for photofacial rejuvenation, pigment correction, and mild redness reduction.

LP ND Yag 1064nm – Vascular Lesions

Targets unwanted vascular structures including spider veins, facial vessels, leg veins, telangiectasia, and rosacea‑related redness. Effective for treating diffuse redness, broken capillaries, and deeper vascular lesions on the face and body. Provides mild skin‑tightening benefits due to deep dermal heating.

Rapid-Vanish MANUFACTURER NOTES

The SharpLight Rapid‑Vanish is a dedicated DPC/IPL platform designed for efficient hair removal and light‑based skin treatments.

The HR 635 applicator delivers controlled broad‑spectrum pulses within the 600–950 nm range, utilizing Dynamic Pulse Control to modulate fluence, pulse width, and pulse sequencing for optimized energy deposition across varying skin types and treatment indications.

When configured with the optional 1064 nm long‑pulse Nd:YAG handpiece, the system extends its capabilities to include deeper vascular targeting. The long‑pulse Nd:YAG wavelength provides enhanced penetration and selective absorption within oxyhemoglobin, enabling effective treatment of telangiectasia, spider veins, and diffuse facial erythema with minimal epidermal disruption.

Both handpieces are designed as durable, reusable optical delivery systems with long‑life lamp and laser components. Treatment parameters—including fluence, pulse duration, and repetition rate—are adjusted through the integrated touchscreen interface, allowing precise control of energy delivery and patient‑specific customization.

Frequently Asked Questions

1. When do I switch between the LP Nd:YAG laser and the Dual VP (DPC) handpiece?

Operators must choose the correct technology based on the depth and size of the vascular or pigmented lesion. The LP Nd:YAG 1064 nm laser is requested for deeper dermis penetration to target thicker, deeper vascular structures like varicose veins. The Dual VP (DPC) handpiece is used for superficial epidermal lesions, facial flushing, erythema, and rosacea.

2. How do I adjust pulse parameters for different Fitzpatrick skin types?

Because the Rapid-Vanish system delivers exceptionally high energy (up to 350J/cm²), adjusting parameters is critical to preventing thermal skin damage. Operators frequently consult the SharpLight Clinical Guidelines to safely adjust the pulse duration (ranging from 10–30ms) and use configurations like Smooth Pulse or Long Pulse to protect darker skin tones (Fitzpatrick types IV–VI).

3. What are the specific eyewear and room safety requirements?

The Rapid-Vanish is a multi-wavelength platform emitting both intense pulsed light and Class 4 laser radiation. Operators frequently verify that both the practitioner and the patient are wearing wavelength-appropriate protective eyewear matching both the DPC spectrum and the 1064 nm Nd:YAG wavelength. The treatment environment must also be completely free of flammable materials and reflective surfaces.

4. What is the expected shot life and maintenance routine for the handpieces?

Clinic operators manage their overhead by tracking handpiece longevity. The flashlamp and laser configurations have distinct lifespans, typically rated for approximately 150,000 exposures per cycle before requiring refurbishment or replacement through the manufacturer’s SharpCare Support Division. Operators also frequently ask about proper cooling gel application and cleaning protocols to maintain the light guides.
